UltraCam Eagle 4.1

Push the limits of your aerial missions



UltraCam Eagle 4.1 aerial camera

Most versatile photogrammetric large-format aerial camera

The UltraCam Eagle 4.1 is a nadir photogrammetric aerial camera system featuring an industry-leading footprint and three user-exchangeable lens kits to augment flight efficiency at true mapping-grade image quality for precise analysis and interpretation.

Download brochure

UltraCam Eagle 4.1 aerial camera

Most versatile photogrammetric large-format aerial camera

The UltraCam Eagle 4.1 is a nadir photogrammetric aerial camera system featuring an industry-leading footprint and three user-exchangeable lens kits to augment flight efficiency at true mapping-grade image quality for precise analysis and interpretation.

Download Brochures


UltraCam Eagle 4.1
Graz, Austria 2022 · 2,5 cm GSD · RGB

Features


UltraCam Eagle 4.1 camera head

The mapping-grade nadir aerial camera to help you succeed in today's geospatial market.
The UltraCam Eagle 4.1 collects high-resolution panchromatic, R, G, B and NIR information at over 500 Megapixels and at a rapid cycle rate of 1 frame every 0.7 seconds. The Eagle 4.1 is the obvious choice for high collection efficiency combined with maximum accuracy.

You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.

More Information


rectangular PAN channel

Combining panchromatic and full-resolution color imagery for highest image-resolving power and utmost detail and accuracy.

Amount of pixel across the flight strip

The UltraCam Eagle 4.1 has an industry-leading footprint of 28,110 pixels across the flight strip, resulting in increased flight collection efficiency.



Adaptive Motion Compensation (AMC)

The 4th generation UltraCam is further enhanced by Vexcel's proprietary Adaptive Motion Compensation (AMC) software approach for multi-directional image blur correction.

Airborne system with very fast frame rate
The ultra-fast frame rate of 1 frame per 0.7 seconds allows for rapid data collection at 5cm GSD with 80% forward overlap at up to 195 knots.

Three user-exchangeable lens kits
UltraCam lens exchange

Opting for flexibility.
User-exchangeable lens kits allow customers to take full advantage of the entire footprint—of more than 28,000 pixels across the flight strip—at different altitudes. Three different focal lengths of 90 mm, 120 mm, and 150 mm are available. The lens change procedure is straightforward and supported by a radiometric and geometric validation process. Even after multiple lens exchanges, photogrammetric-grade accuracy is maintained. Learn more about our custom lens technology here.

UltraCam Eagle 4.1 footprint

Greatest efficiency for all use cases.
The 500 Megapixel footprint can be exploited at different altitudes without compromising data quality, thanks to three field-exchangeable lens kits. The Eagle 4.1 is the system of choice for applications ranging from low altitude engineering collections to high altitude orthophotography projects.

UltraCam Eagle 4.1 Webinar

Learn about the key features of the UltraCam Eagle 4.1 aerial camera and UltraNav v7 flight management and georeferencing solution.

Watch the webinar
Nadir aerial image with 5cm GSD

Progress and perfection based on sound photogrammetric principles.
Built on proven 4th generation UltraCam architecture, the UltraCam Eagle 4.1 features CMOS sensors for a finer pixel pitch and new custom lenses, coupled with new electronics, to provide customers with imagery of exceptional sharpness, detail, and image dynamic. All these new components have been carefully designed and integrated, based on our longstanding and successful photogrammetric legacy, to ensure the highest possible quality outputs for current and future customer needs.

Accurate and visually impressive imagery through Adaptive Motion Compensation.
Introduced with the 4th generation UltraCam architecture, Vexcel's proprietary Adaptive Motion Compensation (AMC) plays a significant role in the enhanced quality of imagery produced by the UltraCam Eagle 4.1 and other UltraCam 4th generation systems. This software-based approach corrects all image motion blur, regardless of direction and image scale. The result is imagery that is exceptionally sharp and detailed. In the above image at a zoom level of 200%, the difference between no motion compensation and AMC can be observed by moving the arrow left and right.

Nadir aerial image of Gleisdorf, Austria

Sophisticated image processing in UltraMap.
The UltraCam Eagle 4.1 is fully supported in the UltraMap workflow that consists of five consecutive modules in one intuitive user interface for consistent user experience. Data products produced by UltraMap include visually stunning and photogrammetric-grade quality images, meta data such as point clouds, DSMs, DTMs and 3DTins at highest geometric accuracy levels.

Learn more

4th generation design updates.
The Eagle 4.1 builds on the 4th generation camera design, offering even more user-friendly and intuitive camera operation. The Eagle 4.1 allows easy access to the IMU and UltraNav. The small form factor of the camera head makes it suitable for smaller aircraft. The ridged cylinder design enables precise and easy installation to the mount. Ergonomic handles, more robust ports and an anti-scratch coating enhance overall usability.

Ridged cylinder design for straightforward installation
Digital large format camera for nadir image collection
UltraCam Eagle 4.1 detail
Vexcel Imaging airborne system
Kaoru Orimo, UltraCam Eagle customer

"We continue to choose the UltraCam Eagle over other systems on the market because of its large footprint, the user-exchangeable lens system and its state-of-the-art technology. With the Eagle 4.1, we can provide our customers with highest quality imagery and data."

KAORU ORIMO, ULTRACAM EAGLE CUSTOMER

UltraMount provided by Vexcel Imaging

Smooth sailing.
The UltraMount product line dynamically stabilizes the UltraCam Eagle 4.1 aerial camera in the aircraft for blur-free, consistent, and aligned exposures.

Learn more

Always on track.
Flight management and georeferencing with UltraNav optimizes your flight mission for utmost productivity at highest precision.

Learn more
UltraNav flight management


The UltraCam Eagle 4.1:
Opens up new possibilities.

Request a demo
